The Combine Soybean Harvester is excellent Combine Harvesting and Threshing Machine for Soybean, Rice and Wheat , Sorghum, Millet etc.

It combines grain plants cutting, conveying , grain threshing and cleaning perfectly, to improve 200% harvesting efficiency and save so much labour cost.

Considering the multi functions it can do for farmers, the 4HYM-1.2L Combine Soybean Harvester is the first agriculture equipment we should invest in.

Large Wheel Combine Harvester VS 4HYM-1.2L Soybean Harvester

For most farmers, how to get affordable and suitable combine harvester is a good question.

Traditional Large Wheel combined harvester are big capacity, and suitable for more than 2000 hectares field.  They are huge working measurement,  not able to work at small land, and hard to transport abroad.

To meet more medium and small land farmers requirement,  we make the 4HYM-1.2L Combine Soybean Harvester.  It can work perfectly not only at plain field, but also small plot and terrains smaller than 2000 hectares.

Besides, the Soybean Harvester are Crawler Wheel. This design provides better stability and weight distribution, making them suitable for operating in challenging terrains.

With the combine harvester,  you can harvest Soybean, Sorghum, Beans, Rice, Millet with high efficiency.

Advantages:

• Apply for harvesting Sorghum, Sorghum, Rice, Beans, Wheat, Barley , Millet etc.
• Combine harvesting, threshing, cleaning and collecting grains directly into the bag.
• Light weight, Easy to move to field.
• Specially have advantage for the small land , mountainous area and hilly terrain.
• Affordable for every farmers.

Technical Parameter of the Combine Soybean Harvester

Name	Combine Soybean Harvester
Model	4HYM-1.2L
Driver seat	Flexible
Wheel type	Crawler wheel type
Harvesting width	1.2 m
Driven power	25 HP Diesel engine
Productivity	3-5 hectare/h
Feeding speed	> 1 kg/s
Fuel consumption	2-2.5 L/ha
Stubble height	12-75 cm
Crawler width	255 mm
Outer dimension	3320*1510*2420mm
Loss rate	≤3%
Weight	1000 kg

Combine Soybean Harvester working at hilly Soybean field

Pictures of the Combine Soybean Harvester

Beans elevator or Beans chute in the Beans Collection Box . It can upload Beans automaticlly afterwards.

Hopper at the rear of the Harvest machine

Durable Crawler wheel work at both wet and dry field.  and it has less damage to the soil when harvesting. do plough easier when planting

Durable Cutting blade of the harvester

Durable Screen mesh to deduct impurities

Harvest Sorghum at Mexico

Harvest Soybean in Nigeria

Combine Soybean Harvester ready for delivery

Metal frame and package before delivery

Package open in Africa

Application I :

The 4HYM-1.2L Combine Soybean harvester can harvest all kinds of beans, like Soybean, Chick pea, Mung bean and rapes.

The Mini Combine Soybean Harvester is driven by 25HP diesel engine, which is more powerful than most small harvesters. It can harvest Soya Bean with straw, crush the straw and thresh Soyabean shells systematically. With strong blowing fan and double shaking screen, farmers can get clean soybeans directly.

The Combine Soyabean Harvester has double layer air-flow cleaner, which will keep impurities rate less than 3%.

The Soybean combine harvester adopts double – layer cutter, air – flow cleaning. It can complete the whole process of harvesting, threshing, cleaning, stubble cutting and bagging at one time.

Application II :

The combine soybean harvester can harvest Rice and wheat at both dry and paddy field soil.

Comparing with traditional harvester with rubber wheels, the 4HYM-1.2L Combine rice harvester is crawler wheel. it can not only work well at dry rice field, but also wet soil . the crawler wheel reduce the risk to get stuck to the wet paddy field soil .

The rice harvester operation is light and flexible, the maintenance is convenient, the cleaning mechanism is simple and practical, and has the characteristics of low impurity content, small loss and high efficiency.

Advantages of the 4HYM-1.2L Soybean harvester

• Good passability in paddy mud field

The chassis has high ground clearance, and the track can be rotated in both positive and negative way, as well as braking and turning left and right. It has good passability and cross-country in paddy field. the soybean harvester work normally in the paddy field with mud foot depth less than 25cm.

• Stronger cutting header

To harvest soya bean , the combine harvester has stronger cutting header. it feed in hard soybean straw more efficiently and harvest beans with higher capacity.

• Double cutting blades to harvest Soybean and rice with shorter stubble

The 4HYM-1.2L is installed with two pairs of cutting blades. the up cutting blade pick up the beans from straw effectively and transfer to the threshing room.

the down cutting blade cut straw with lower stubble, thus the field is easier to plough after harvesting. what’s more, it reduce the fuel consuption.

• Double operation tables to be more safe and flexible

The operate more safe and flexible, the combine harvester has two operation tables. one is in front of the seat. another is at right side of the seat. thus driver can handle more conveniently.

• Big grain collecting box and conveying auger to save time for packing

After Soybean and rice threshed，the Soybean harvester will screen twice and wipe out 96% impurity. the clean soybean and rice will be collected by the big white collecting box automaticlly. Farmers can pack the collect grains to bags when the machine stops working , no need to pack frequently with small bags.

there is an auger inside the collecting box. open the outlet, soybean and rice will be upload to your bag automaticlly, not necessary to carry out manually.

• Low breakage rate, high feedback and short payback period

The 4HYM-1.2L mini Combine harvester has been updated for 3 generation. it is so professional and excellent at harvesting soybean and rice that more than 50000 farmers from different countries give us good feedback.

It is a good investment for your farm, which can bring feedback in short time.

• Small damage to the field

Working with crawler wheels, the harvester weight spread bigger and reduce pressure for the field. During harvesting, there is small damage to the hard strata of the paddy field. After harvesting, the surface of the paddy field is smooth, providing convenient conditions for the cultivation of the next season.

How to guarantee delivery of the 4HYM-1.2L Soybean harvester for my farm ?

The 4HYM-1.2L Combine soybean harvester are rather popular with farmers , after soybean harvesting season testing. it harvest the soybean with high efficiency and good performance . Therefore, orders are pouring in our factory.

To guarantee the delivery, our factory are manufacturing the machines in three shifts every day. Orders will be arranged in turn and send out soonest from CHINA.
